MAR-VAN Ceiling framework - For Ducato / Boxer / Jumper 2006+ / Movano 2021+ / Proace Max 2024+
Extension module for the basic MAR-VAN wall framework.
| Category: | FRAMEWORKS |
|---|---|
| EAN: | Choose variant |
| ? For vehicle: | Fiat/Peugeot/Citroen, Opel, Toyota, Renault |
| ? Type: | Ceiling framework |
We ourselves have often struggled with ceiling cladding, how to create a level surface, bridge protruding body parts, and finally elegantly connect it to the wall cladding. Finally, however, we have a solution not only for our conversions, but also for you. With this module, you can easily solve the ceiling structure even in the case of the challenging plastic roofs of some vans.
Screws, washers, and nuts are required for assembly. Composition: screw, washer, structural rib, ceiling rib, washer, spring washer, nut. The mounting kit, which contains everything you need, can be found at this link., which contains everything you need.
The final cladding is your choice. You can use tongue and groove boards of various thicknesses and widths, lightweight and waterproof plywood, honeycomb panels, faux leather, and so on.
Package includes:
| Model | Ceiling Ribs | Positioning Ribs | Beams | Weight (kg) |
| MAR 254 | MAR 206 | MAR 146 | ||
| L2H2 | 6 | 4 | 5 | 7 |
| L3H2 | 7 | 4 | 6 | 8 |
| L4H2 | 8 | 4 | 6 | 9 |
| MAR 254 | MAR 290 | MAR 146 | ||
| L3H3 | 7 | 4 | 6 | 8 |
| L4H3 | 8 | 4 | 6 | 9 |
